Make Manche Great Again
Project Make Manche Great Again stemmed from our one co-owners desire to always build a Comanche. It started with a very sad Comanche that we knew had potential to be something great again. The base vehicle started as a 1986 Jeep Comanche base package. It has since been converted to a formidable rock crawling machine. The entire drive train has been swapped, the interior and front clip have been converted to 97-01 Jeep Cherokee components and to top it all off, its sporting a 10" bed bob. This project like any, still has more to come, so keep checking back for updates. Let's get into the specs on thing!
​
Engine
-
4.0L Inline Six, (2005 Model Year)
-
SS Header
-
Upgraded 4 hole injectors
-
Ported throttle body
-
3 Electric Fan Set Up
Transmission​
-
NSG370 6 Speed (2005 Model Year)
Transfer Case​
-
NP231J
-
Tom Woods Super Duty SYE
Front Axle​
-
1986 Jeep J20 Dana 44 HD
-
Barnes 4WD Swap Truss System
-
Ballastic Fab Inner C Gussets
-
OHF Fabricated Diff Cover
-
OHF Custom Steering and Track Bar
-
Revolution Gear and Axle 4.88s
-
Torq Master Locker
-
Warn Premium Lockouts
Rear Axle​
-
1986 Jeep J20 Full Float Dana 60
-
Chassis Unlimited Truss
-
Barnes 4WD U Bolt Eliminator Spring Perches
-
Yukon 4.88 Gears
-
Dana 60 Trak Lok Limited slip
Suspension​
-
6" Metal Cloak Front Coil Springs
-
BDS Long Arm Upgrade
-
Spring Over Rear Axle, w/ shackle relocation
-
12" Doestech Shocks (All 4 Corners)
Wheels & Tires​
-
37x12.50R17 Milestar Patagonia MT
-
Custom Painted 17" Hummer H2 Wheels
Armor​
-
OHF XJ/MJ Insanity Front Bumper
-
OHF Custom MJ Rear Bumper
-
OHF MJ Long Bed Intensity Rock Sliders
-
OHF Custom Gas Tank Relocation Skid Plate
-
OHF Custom MJ Steel Fender Flares
Misc.​
-
97-01 Cherokee Front Clip Swap
-
97-01 Cherokee Interior Swap
-
JCR Center Console Bracket
-
Rod Louver's XJ Hood Louvers
-
Truck Lite LED Headlights
-
Smoked Turn Signal/Side Marker Lights
-
Rusty's Steel Tail Light Buckets w/ LED Lights
-
10" Bed bob
​​
​
​
​
​
